Medical Display Solutions
Precision diagnostic displays for clinical imaging systems
Our medical-grade displays maintain stable DICOM GSDF image quality for diagnostic use. Built for hospital environments, they support regular calibration, easy disinfection and seamless connection with PACS systems. Custom optical and size options are available for medical device manufacturers.
Unstable Grayscale & Luminance Drift
Deviated image quality leads to misdiagnosis risk
Medical displays suffer gradual brightness and grayscale shift over runtime. Without stable DICOM GSDF performance, subtle lesions may be missed and bring diagnostic risks.
Time-consuming regular QA work for biomedical teams
Periodic manual DICOM calibration and QA logging are required. Hospitals need dedicated biomedical engineers, raising long-term operational cost and workload.
Signal lag & rendering inconsistency disrupt clinical workflow
Many displays have limited interoperability with PACS, EHR and surgical video systems. Signal switching delay and inconsistent image rendering disrupt clinical workflow.
Ordinary panels fail to withstand disinfection and glare
Operating rooms and wards require frequent disinfection, splash resistance and anti-glare. Ordinary panels are vulnerable to chemical corrosion and reflected light interference.
PRODUCT PARAMETERS
Match the panel to the project
| Model | Size | Resolution | Brightness | Interface | Operating temperature |
|---|---|---|---|---|---|
| MD070-HB01 | 7.0 inch | 800 × 480 | 1,000 cd/m² | LVDS | −20 to 70°C |
| Model | Size | Resolution | Brightness | Interface | Operating temperature |
|---|---|---|---|---|---|
| MD101-IPS02 | 10.1 inch | 1280 × 800 | 500 cd/m² | LVDS | −20 to 70°C |
| Model | Size | Resolution | Brightness | Interface | Operating temperature |
|---|---|---|---|---|---|
| MD121-WT03 | 12.1 inch | 1024 × 768 | 800 cd/m² | LVDS | −30 to 80°C |
| Model | Size | Resolution | Brightness | Interface | Operating temperature |
|---|---|---|---|---|---|
| MD156-IPS01 | 15.6 inch | 1920 × 1080 | 400 cd/m² | eDP | −20 to 70°C |
| Model | Size | Resolution | Brightness | Interface | Operating temperature |
|---|---|---|---|---|---|
| MD043-IPS01 | 4.3 inch | 480 × 272 | 500 cd/m² | RGB | −20 to 70°C |
| MD215-IPS01 | 21.5 inch | 1920 × 1080 | 350 cd/m² | LVDS | 0 to 50°C |
Related Products
Related Products
Relevant Cases
Proven automotive display projects for OEM and Tier 1 partners
Send your specifications for engineering review
A drawing, datasheet, or current part number helps us evaluate the right path faster.
