Description
10.4 inch TFT LCD display Description
Here are the key points about this 10.4 inch TFT LCD display :
- Product Specs: 10.4 inch TFT LCD display ; 1024×768 (XGA) resolution; IPS panel with stable color reproduction and wide 80/80/80/80 viewing angle; square-like aspect ratio, cost-optimized alternative to mainstream supplier displays with full form-factor compatibility
- Applications: Suitable for industrial user interfaces, legacy system upgrades, industrial HMI, instrumentation, medical equipment, transportation systems, charging stations, and control panels requiring long-term stability and readability
High brightness industrial LCD
| High brightness industrial LCD Specifications | |||
| Model Number | 90-10401-001 | Operating Temperature | -30~80 |
| Size | 10.4 | Storage Temperature | -30~80 |
| Resolution | 1024*768 | Contrast Ratio | 1000:1 |
| Outline Dimension | 238.6*175.8*6.8 | LED Lifetime | 20000 |
| Active Area | 210.432*157.824 | Touchscreen Support | No |
| Brightness(cd/m²) | 700 | Power Supply | 3.3V |
| Interface | LVDS | Display Type | Color LCD |
| View Direction | IPS | ||
Customizable Parts
Display Cable
We can adjust the length, position, and pins of the cable according to your needs, or add additional connectors to enhance its functionality. Through customization, you can make your circuit connections safer and achieve more reliable performance.
Customized glass and touch screen
In order to improve the durability and performance of the monitor, you can choose to have a custom-cut cover glass for your monitor. You can select the thickness that suits you and opt for the optical bonding method, thus providing the monitor with protection against moisture and breakage.
Contact us to get the best customized solution.
Beyond these tailored services, our displays excel in diverse industry applications: Medical displays feature 1000-nit brightness and antibacterial glass for clear, sterile surgical environments; automotive console displays prioritize reliability; industrial HMIs use M12 connectors and IP67 coating to withstand harsh conditions; and visual access control displays deliver high brightness, HD quality, with customizable shapes. Submit your project requirements via our form, and our experts will provide a personalized solution framework within 48 hours.
