Description
AUO G270HAN01.0 Key Features
Here are the key points about this AUO G270HAN01.0 TN LCD Screen :
- The AUO G270HAN01.0 TN LCD Screen is a 27-inch FHD (1920×1080) industrial LCD screen designed for high-performance environments.
- Featuring a 1000cd/m² ultra-bright IPS panel with 89° wide viewing angles, it ensures clarity in direct sunlight or harsh lighting.
- Built with an LVDS interface and 50,000-hour LED lifespan, it guarantees stable connectivity and durability.
- Its wide operating temperature range (-0°C to 50°C) suits extreme conditions, while the 1000:1 contrast ratio delivers vivid color reproduction.
- Ideal for industrial control systems, outdoor kiosks, and medical equipment, this display combines reliability with energy-efficient 12V power design.
27″ TN LCD Specifications
| 27.0″ LCD Display Specifications (Model: G270HAN01.0) | |||
| Model Number | G270HAN01.0 | Operating Temperature | 0℃ to 50℃ |
| Display Size | 27.0 inch | Storage Temperature | -20℃ to 60℃ |
| Resolution | 1920 × 1080 (Full HD) | LED Lifetime | 50,000 hours |
| Outline Dimensions | 630mm × 368.2mm × 23.4mm | Touchscreen | No |
| Active Area | 597.888mm × 336.312mm | Contrast Ratio | 1000:1 |
| Brightness | 300 cd/m² | Power Supply | 12.0V DC |
| Interface | LVDS | Display Type | Color LCD |
| View Direction | IPS (In-Plane Switching) | ||
Customizable Parts
Display Cable
We can adjust the length, position, and pins of the cable according to your needs, or add additional connectors to enhance its functionality. Through customization, you can make your circuit connections safer and achieve more reliable performance.
Customized glass and touch screen
In order to improve the durability and performance of the monitor, you can choose to have a custom-cut cover glass for your monitor. You can select the thickness that suits you and opt for the optical bonding method, thus providing the monitor with protection against moisture and breakage.
Contact us to get the best customized solution.
Beyond these tailored services, our displays excel in diverse industry applications: Medical displays feature 1000-nit brightness and antibacterial glass for clear, sterile surgical environments; automotive console displays prioritize reliability; industrial HMIs use M12 connectors and IP67 coating to withstand harsh conditions; and visual access control displays deliver high brightness, HD quality, with customizable shapes. Submit your project requirements via our form, and our experts will provide a personalized solution framework within 48 hours.
