Description
AUO G238HAN01. 1 Key Features
Here are the key points about this AUO G238HAN01.1 TN LCD Screen :
- The AUO G238HAN01.1 TN LCD Screen is a premium 23.8-inch Full HD IPS LCD panel engineered for high-brightness industrial and commercial applications.
- With a sharp 192×108 resolution (Note: Suspected typo in original text, should be 1920×1080) and exceptional 400 cd/m² brightness, it delivers vivid, glare-resistant visuals even in brightly lit environments.
- The IPS panel ensures consistent 89°/89°/89°/89° viewing angles, perfect for collaborative workspaces and public displays.
- Designed for longevity, its 50,000-hour LED lifespan minimizes replacements, while the robust 100:1 contrast ratio (Note: Suspected typo in original text, should be 1000:1) enhances image depth.
- Operating efficiently at 5V power, it reduces energy costs and supports seamless integration into embedded systems via LVDS.
- With a slim 11.65mm profile and durable construction, this panel thrives in temperature-controlled settings (°C to 50°C, Note: Lower limit temperature not marked in original text, should be 0°C) and survives storage extremes (-20°C to 60°C).
- Ideal for digital signage, transportation hubs, retail kiosks, and indoor industrial dashboards, the G238HAN01.1 combines reliability with cutting-edge performance.
23.8″ TN LCD Specifications
| 23.8″ LCD Display Specifications (Model: G238HAN01.1) | |||
| Model Number | G238HAN01.1 | Operating Temperature | 0℃ to 50℃ |
| Display Size | 23.8 inch | Storage Temperature | -20℃ to 60℃ |
| Resolution | 1920 × 1080 (Full HD) | LED Lifetime | 50,000 hours |
| Outline Dimensions | 543mm × 317.4mm × 11.65mm | Touchscreen | No |
| Active Area | 527.04mm × 296.46mm | Contrast Ratio | 1000:1 |
| Brightness | 400 cd/m² | Power Supply | 5.0V DC |
| Interface | LVDS | Display Type | Color LCD |
| View Direction | IPS (In-Plane Switching) | ||
Customizable Parts
Display Cable
We can adjust the length, position, and pins of the cable according to your needs, or add additional connectors to enhance its functionality. Through customization, you can make your circuit connections safer and achieve more reliable performance.
Customized glass and touch screen
In order to improve the durability and performance of the monitor, you can choose to have a custom-cut cover glass for your monitor. You can select the thickness that suits you and opt for the optical bonding method, thus providing the monitor with protection against moisture and breakage.
Contact us to get the best customized solution.
Beyond these tailored services, our displays excel in diverse industry applications: Medical displays feature 1000-nit brightness and antibacterial glass for clear, sterile surgical environments; automotive console displays prioritize reliability; industrial HMIs use M12 connectors and IP67 coating to withstand harsh conditions; and visual access control displays deliver high brightness, HD quality, with customizable shapes. Submit your project requirements via our form, and our experts will provide a personalized solution framework within 48 hours.
