Description
JZ-VDH68 V1.1 TFT LCD Driver Board
- Product Specs: JZ-VDH68 V1.1 TFT LCD driver board , -20~65℃ working temp, optional auto light control, max 1920×1200 resolution, up to 85Hz refresh rate, 2×10W amplifier, IR remote & serial port control
- Applications: Industrial and embedded display equipment
- Manufacturer Support: Stable hardware with customizable functions
| Main Features | |||||
| Display Output | Maximum Resolution | Max. 1920×1200 | |||
| Output Interface | Single/Dual LVDS | ||||
| Supported Signals | Analog RGB | Horizontal Freq: 30-120KHz Vertical Freq: 50-75Hz 0.7Vp-p@75ohm Separate/Composite/SOG sync support | |||
| Digital DVI/HDMI | Horizontal Freq: 30-120KHz Vertical Freq: 50-75Hz 0.7Vp-p@75ohm Separate/Composite/SOG sync support | ||||
| Buttons | Power, Menu, Exit, Plus, Minus | ||||
| Menu Type | Graphical OSD | ||||
| Language Support | Chinese, English, and 8 other languages | ||||
| Function Operations | Picture | Mode/Brightness/Contrast/Saturation/Sharpness/Hue | |||
| Function | Language/Reset/Color Temp. | ||||
| PC | Clock/Phase/H position/V position/Auto configure | ||||
| Power supply | Stand-by | <0.5W 12Vstb/200mA | |||
| Input | 12V/dc | ||||
| Interface Definition | |||||
| LVDS/eDP DuPont output | |||||
| Pin No. | Function | Pin No. | Function | Pin No. | Function |
| 1 | VCC | 11 | RXO2-/LANE1_N | 21 | RXE1- |
| 2 | VCC | 12 | RXO2+/LANE1_P | 22 | RXE1+ |
| 3 | VCC | 13 | GND | 23 | RXE2- |
| 4 | AUX_CH_P | 14 | GND | 24 | RXE2+ |
| 5 | AUX_CH_N | 15 | RXOC- | 25 | GND |
| 6 | GND | 16 | RXOC+ | 26 | GND |
| 7 | RXO0- | 17 | RXO3- | 27 | RXEC- |
| 8 | RXO0+/eDP_HPD | 18 | RXO3+ | 28 | RXEC+ |
| 9 | RXO1-/LANE0_N | 19 | RXE0- | 29 | RXE3- |
| 10 | RXO1+/LANE0_P | 20 | RXE0+ | 30 | RXE3+ |
| eDP FPC output (30-pin) | |||||
| Pin No. | Function | Pin No. | Function | Pin No. | Function |
| 1 | NC | 11 | GND | 21 | GND |
| 2 | GND | 12 | VLCD | 22 | EN |
| 3 | LANE1_N | 13 | VLCD | 23 | ADJ |
| 4 | LANE1_P | 14 | NC | 24 | NC |
| 5 | GND | 15 | GND | 25 | NC |
| 6 | LANE0_N | 16 | GND | 26 | +12V |
| 7 | LANE0_P | 17 | eDP_HPD | 27 | +12V |
| 8 | GND | 18 | GND | 28 | +12V |
| 9 | AUX_CH_P | 19 | GND | 29 | +12V |
| 10 | AUX_CH_N | 20 | GND | 30 | NC |
| Backlight Board Port | |||||
| Pin No. | Function | Pin No. | Function | Pin No. | Function |
| 1 | 12V | 3 | EN | 5 | GND |
| 2 | 12V | 4 | ADJ | 6 | GND |
Customizable Parts
Display Cable
We can adjust the length, position, and pins of the cable according to your needs, or add additional connectors to enhance its functionality. Through customization, you can make your circuit connections safer and achieve more reliable performance.
Customized glass and touch screen
In order to improve the durability and performance of the monitor, you can choose to have a custom-cut cover glass for your monitor. You can select the thickness that suits you and opt for the optical bonding method, thus providing the monitor with protection against moisture and breakage.
Contact us to get the best customized solution.
Beyond these tailored services, our displays excel in diverse industry applications: Medical displays feature 1000-nit brightness and antibacterial glass for clear, sterile surgical environments; automotive console displays prioritize reliability; industrial HMIs use M12 connectors and IP67 coating to withstand harsh conditions; and visual access control displays deliver high brightness, HD quality, with customizable shapes. Submit your project requirements via our form, and our experts will provide a personalized solution framework within 48 hours.
