6.8 Inch 5-Point Capacitive Touch Screen Panel
Here are the key points about this 6.8 Inch 5-Point Capacitive Touch Screen :
Premium Projected Capacitive Touch Panel
Engineered for precision and durability, this industrial-grade 5-point multi-touch screen features cutting-edge mXT640U controller IC, delivering ultra-responsive gesture recognition (pinch, zoom, swipe) and <2ms response time. The robust G+G (Glass+Glass) structure combines chemically strengthened 1.1mm cover lens with sensor glass, achieving 7H hardness and IP65-rated dust/water resistance for 24/7 operation in harsh environments.
Advanced Features:
5 simultaneous touch points with palm rejection
10-million-touch lifespan (IEC 60068-2-27 certified)
EMI/ESD protection (IEC 61000-4-2 Level 4 compliance)
Customizable FPC length (50-300mm optional)
| Capacitive Touch Screen Panel | ||
| Construction | Cover Glass | Thickness: 1.1mm±0.05mm |
| OCR | Thickness: 0.175mm ± 0.05mm | |
| ITO Glass | Double side ITO glass: Thickness: 0.4mm ± 0.05mm | |
| Machanical Characteristics | Touch size | 6.8 inch |
| Outer Dimension | 190.66*75.01 | |
| Посмотреть область | 161.59*61.22 | |
| Sensor Area | 169.55*74.41 | |
| Cover Thickness | 1.1 | |
| Number of Touch | 5 | |
| Интерфейс | I2C | |
| Controller | Microchip | |
Miqidisplay touch screen solutions support a maximum size of 32 inches and feature full lamination for PCAP and TFT displays. They offer flexible connectivity options, including USB and IIC, along with debugging capabilities for enhanced functionality. You can customize the cover lens with options such as anti-glare (AG), anti-reflective (AR), anti-fingerprint (AF), or anti-bacterial (AB) coatings. Additionally, these displays support multi-touch, waterproof touch, and glove touch functionalities, ensuring high stability and excellent resistance to interference, making them ideal for various applications.
