23.8″ 5-Point Custom Capacitive Touch Panel
Here are the key points about this 23.8″ 5-Point Custom Capacitive Touch Panel :
Introducing our high-performance 23.8-inch Custom Capacitive Touch Panel, engineered for precision and durability in demanding environments. Featuring 5-point multi-touch responsiveness, this panel delivers seamless interaction for industrial, commercial, and interactive display applications.
Advanced Features:
IP65-rated front panel (optional) for dust/water resistance.
Supports gloved or bare-hand operation.
Certified with CE/FCC/RoHS standards
Frame modifications (VESA mount, flush/bezel mounting)
| 23.8″ Custom Capacitive Touch Panel | ||
| Construction | Cover Glass | Thickness: 6 mm±0.05mm |
| OCR | Thickness: 0.2mm ± 0.05mm | |
| ITO Glass | Double side ITO glass: Thickness: 1.1mm ± 0.05mm | |
| Machanical Characteristics | Touch size | 23.8 inch |
| Outer Dimension | 563*337.4 | |
| Посмотреть область | 530.44*299.86 | |
| Sensor Area | 548.6*332.23 | |
| Cover Thickness | 6 | |
| Number of Touch | 5 | |
| Интерфейс | USB | |
| Controller | Microchip | |
Miqidisplay touch screen solutions support a maximum size of 32 inches and feature full lamination for PCAP and TFT displays. They offer flexible connectivity options, including USB and IIC, along with debugging capabilities for enhanced functionality. You can customize the cover lens with options such as anti-glare (AG), anti-reflective (AR), anti-fingerprint (AF), or anti-bacterial (AB) coatings. Additionally, these displays support multi-touch, waterproof touch, and glove touch functionalities, ensuring high stability and excellent resistance to interference, making them ideal for various applications.
