DV170YGM-N10 General Description
Here are the key points about this BOE DV170YGM-N10 IPS LCD Display :
The BOE DV170YGM-N10 IPS LCD Display is a robust 17.0-inch color LCD display engineered for demanding environments.
Featuring an IPS panel with 1280×960 resolution and 89/89/89/89 ultra-wide viewing angles, it delivers consistent clarity from any direction.
With 250 cd/m² brightness and 1000:1 contrast ratio, it remains visible even in bright lighting conditions.
The LVDS interface ensures stable signal transmission, while its rugged design supports operation in temperatures from 0°C to 50°C.
Built for longevity, its 50,000-hour LED lifespan minimizes downtime.
Compact dimensions (359×284.8×13.3mm) and a lightweight profile make it ideal for space-constrained installations.
DV170YGM-N10 Application & Performance
The DV170YGM-N10 works for industrial automation, medical devices and outdoor kiosks, excelling in extreme conditions. Its IPS ensures accurate color for critical monitoring; wide temperature tolerance fits harsh environments like factories and outdoor signage. High brightness/contrast boost sunlight readability, with LVDS ensuring compatibility with industrial control systems. Durable and energy-efficient (5.0V), it cuts operational and maintenance costs, delivering reliable performance in precision-required scenarios like machinery HMI, diagnostic equipment and transportation displays.
BOE DV170YGM-N10 Specifications
| BOE DV170YGM-N10 Specifications | |||
| Display Size | 17.0 inch (431.8 mm) | 명암비 | 1000:1 (typical) |
| 해상도 | 1280 × 960 (SXGA) | 작동 온도 | 0°C to +50°C |
| 명도 | 250 cd/m² | 보관 온도 | -20°C to +60°C |
| Module Dimensions | 359 × 284.8 × 13.3 mm | Backlight Lifetime | 50,000 시간 |
| 활성 영역 | 345.408 × 259.056 mm | 전원 공급 장치 | 5.0V ±5% |
| Panel Technology | IPS (In-Plane Switching) | Touch Panel | Not included |
| 보기 각도 | 89°/89°/89°/89° (U/D/R/L) | 디스플레이 유형 | 색상 TFT LCD |
| 인터페이스 | LVDS (Low Voltage Differential Signaling) | ||
사용자 지정 가능한 부품
디스플레이 케이블
We can adjust the length, position, and pins of the cable according to your needs, or add additional connectors to enhance its functionality. Through customization, you can make your circuit connections safer and achieve more reliable performance.
맞춤형 유리 및 터치 스크린
모니터의 내구성과 성능을 향상시키기 위해 모니터용 커스텀 커팅 커버 유리를 선택할 수 있습니다. 자신에게 맞는 두께를 선택하고 광학 접착 방식을 선택하여 모니터를 습기와 파손으로부터 보호할 수 있습니다.
저희에게 연락하십시오 최상의 맞춤형 솔루션을 얻으려면.
Beyond these tailored services, our displays excel in diverse industry applications: Medical displays feature 1000-nit brightness and antibacterial glass for clear, sterile surgical environments; automotive console displays prioritize reliability; industrial HMIs use M12 connectors and IP67 coating to withstand harsh conditions; and visual access control displays deliver high brightness, HD quality, with customizable shapes. Submit your project requirements via our form, and our experts will provide a personalized solution framework within 48 hours.
