Descrizione
G070ACE-LH3 General Description
Here are the key points about this Innolux G070ACE-LH3 Space Warrior LCD :
Model and Size Advantage：Redefining space-critical applications, the Innolux G070ACE-LH3 packs industrial-grade performance into a slim 165×104×8.85mm footprint—12% smaller than standard 7″ displays—ideal for robotic arm control modules and EV battery management dashboards.
Display Performance and Temperature Adaptability：The IPS panel maintains 89° quad-viewing angles even in 85°C engine bay diagnostics, with 500cd/m² brightness cutting through desert off-road vehicle dust clouds.
Interface and Contrast Advantage：LVDS interface ensures zero latency in electromagnetic-heavy environments like welding robot controllers, while 800:1 contrast reveals micro-crack details in foundry quality inspection systems.
Lifespan and Durability：With 50,000-hour lifespan, it withstands 24/7 operation in molten salt reactor monitoring and vibrating grain dryer HMIs.
Extreme Environment Adaptability：The -30°C cold-start capability powers Arctic oil drilling telemetry, and 3.3V low power enables solar-powered wildfire tracking drones.
Innolux G070ACE-LH3 Space Warrior LCD Application & Performance
Designed for confined spaces and thermal extremes, this display drives autonomous forklift dashboards in 85°C warehouse zones and lithium battery pack monitoring in electric supercars. Its compact frame integrates into surgical robot arms for real-time 89° multi-angle imaging during procedures. Vibration resistance ensures stability on mining drill rigs and hypersonic wind tunnel test consoles. The extended thermal range supports cryogenic lab sample tracking (-30°C) and glass furnace control interfaces (85°C). LVDS reliability prevents signal loss in MRI machine control panels, while IP67-rated variants monitor offshore aquaculture cages in salt spray environments. Ideal for satellite test chamber HMIs and mobile artillery targeting systems requiring instant -30°C cold boot.
7.0″ Product Specifications
| 7.0″ IPS TFT LCD Display Specifications | |||
| Dimensione dello schermo | 7.0 inch (178mm diagonal) | Rapporto di contrasto | 800:1 (typical) |
| Risoluzione | 800 × 480 pixels (WVGA) | Temperatura di esercizio | -30℃ to +85℃ |
| Luminosità | 500 cd/m² (typical) | Temperatura di stoccaggio | -30℃ to +90℃ |
| Module Dimensions | 165(W) × 104(H) × 8.85(D) mm | LED Backlight Life | 50,000 hours (minimum) |
| Area attiva | 152.4(W) × 91.44(H) mm | Touchscreen | Not included |
| Angolo di visualizzazione | 89° (U/D/L/R) | Power Requirement | 3.3V DC |
| Interfaccia | LVDS interface | Visualizza tecnologia | IPS Color TFT |
Parti personalizzabili
Cavo del display
We can adjust the length, position, and pins of the cable according to your needs, or add additional connectors to enhance its functionality. Through customization, you can make your circuit connections safer and achieve more reliable performance.
Vetro e touch screen personalizzati
Per migliorare la durata e le prestazioni del monitor, si può scegliere di avere un vetro di copertura tagliato su misura per il monitor. È possibile scegliere lo spessore più adatto e optare per il metodo di incollaggio ottico, in modo da proteggere il monitor dall'umidità e dalla rottura.
Contattaci Per ottenere la migliore soluzione personalizzata.
