Descrizione
AUO G230HAN01.1 Key Features
Here are the key points about this AUO G230HAN01.1 TN LCD Screen :
- The AUO G230HAN01.1 TN LCD Screen is a 23-inch IPS LCD designed for versatile indoor applications, featuring 89°/89°/89°/89° ultra-wide viewing angles for consistent color accuracy in collaborative environments.
- With 1920×1080 Full HD resolution and 1000:1 contrast ratio, it delivers sharp visuals for detailed data analysis.
- The ultra-slim 11mm profile (533.2×312mm) enables space-saving integration in compact systems, while 300 cd/m² brightness ensures clarity in office lighting or retail displays.
- Built for stable operation between -20°C to 60°C, it supports 24/7 use in clinics, factories, and smart buildings.
- The LVDS interface minimizes EMI interference, and 5V low-power design reduces energy costs.
- With 30,000-hour LED lifespan, it’s ideal for long-term deployments.
23″ TN LCD Specifications
| 23″ LCD Display Specifications (Model: G230HAN01.1) | |||
| Numero di modello | G230HAN01.1 | Temperatura di esercizio | 0 ℃ a 50 ℃ |
| Dimensioni del display | 23 inch | Temperatura di stoccaggio | Da -20 ℃ a 60 ℃ |
| Risoluzione | 1920 × 1080 (Full HD) | Durata del LED | 30.000 ore |
| Dimensioni del contorno | 533.2mm × 312mm × 11mm | Touchscreen | No |
| Area attiva | 509.184mm × 286.416mm | Rapporto di contrasto | 1000:1 |
| Luminosità | 300 cd/m² | Alimentazione | 5,0 V DC |
| Interfaccia | LVDS | Tipo di display | LCD a colori |
| Visualizza la direzione | IPS (In-Plane Switching) | ||
Parti personalizzabili
Cavo del display
We can adjust the length, position, and pins of the cable according to your needs, or add additional connectors to enhance its functionality. Through customization, you can make your circuit connections safer and achieve more reliable performance.
Vetro e touch screen personalizzati
Per migliorare la durata e le prestazioni del monitor, si può scegliere di avere un vetro di copertura tagliato su misura per il monitor. È possibile scegliere lo spessore più adatto e optare per il metodo di incollaggio ottico, in modo da proteggere il monitor dall'umidità e dalla rottura.
Contattaci Per ottenere la migliore soluzione personalizzata.
Beyond these tailored services, our displays excel in diverse industry applications: Medical displays feature 1000-nit brightness and antibacterial glass for clear, sterile surgical environments; automotive console displays prioritize reliability; industrial HMIs use M12 connectors and IP67 coating to withstand harsh conditions; and visual access control displays deliver high brightness, HD quality, with customizable shapes. Submit your project requirements via our form, and our experts will provide a personalized solution framework within 48 hours.
