43.8″ Stretched LCD Monitors Features
Here are the key points about this 43.8 inch Stretched Bar TFT Monitor :
- This 43.8 inch Stretched Bar TFT Monitor Advertising Display features an LED backlight with a brightness of 450 cd/m² and offers dual resolution options of 1920 x 540 or 3840 x 1080 pixels, providing sharp and vibrant visuals with a typical contrast ratio of 1100:1.
- It has wide viewing angles of 89° in all directions and a response time of 13 ms for rise and 5 ms for fall, ensuring smooth image transitions.
- Supporting 1.07 billion colors with 72% NTSC coverage, the display is constructed from high gloss profile and tempered materials for durability.
- The active area measures 1071.36 mm in height and 301.32 mm in vertical width, with overall dimensions of 1122.38 mm x 350.6 mm x 50 mm.
- The standard shell color is black, with customization options available to suit specific design requirements.
43.8″ Stretched LCD Monitors Application
The device is powered by an RK3288 CPU and features 2GB of memory along with 8GB of built-in storage, running on Android 7.1.
It supports network connectivity via Ethernet and Wi-Fi.
The device is compatible with a variety of video formats, including WMV, AVI, FLV, RM, RMVB, MPEG, TS, and MP4, as well as image formats such as BMP, JPEG, PNG, and GIF.
Connectivity options include 2 USB ports, a TF card slot, audio output, RJ45 for Ethernet, HDMI OUT, and DC IN.
It features 3 serial port sockets (with at least one supporting RS232) and provides 1 RJ45 port for 100M adaptive Ethernet.
Additionally, it supports 1080P output via its RS232 interface, making it a versatile multimedia solution for various applications.
43.8″ Stretched LCD Monitors Specifications
| 43.8″ Stretched LCD Monitor Specifications | |||
| Dimensione diagonale | 43.8″ (Diagonal) | Network Support | Ethernet, WiFi |
| Risoluzione | 1920×540 / 3840×1080 Pixels | Supporto in formato video | WMV, AVI, FLV, RM, RMVB, MPEG, TS, MP4 Loop, Timer, Insert |
| Area attiva | 1071.36mm (W) × 301.32mm (H) | Supporto del formato di immagine | BMP, JPEG, PNG, GIF |
| Dimensioni del contorno | 1122.38mm (W) × 350.6mm (H) × 50mm (D) | USB Ports | 2 × USB 2.0 |
| processore | RK3288 | Ethernet | 1 × RJ45, 100M adaptive |
| Memoria | 2GB DDR3 | Hdmi | 1 port (supports 1080P output) |
| Sistema operativo | Android 7.1 | Touch Technology | Tocco capacitivo G+G. |
Parti personalizzabili
Cavo del display
We can adjust the length, position, and pins of the cable according to your needs, or add additional connectors to enhance its functionality. Through customization, you can make your circuit connections safer and achieve more reliable performance.
Vetro e touch screen personalizzati
Per migliorare la durata e le prestazioni del monitor, si può scegliere di avere un vetro di copertura tagliato su misura per il monitor. È possibile scegliere lo spessore più adatto e optare per il metodo di incollaggio ottico, in modo da proteggere il monitor dall'umidità e dalla rottura.
Contattaci Per ottenere la migliore soluzione personalizzata.
Beyond these tailored services, our displays excel in diverse industry applications: Medical displays feature 1000-nit brightness and antibacterial glass for clear, sterile surgical environments; automotive console displays prioritize reliability; industrial HMIs use M12 connectors and IP67 coating to withstand harsh conditions; and visual access control displays deliver high brightness, HD quality, with customizable shapes. Submit your project requirements via our form, and our experts will provide a personalized solution framework within 48 hours.
