Descrizione
3.5″ TFT Module with IPS Technology
Here are the key points about this 3.5 inch Industrial Crystal Display :
- The 3.5 inch Industrial Crystal Display offers an 80° viewing angle in all directions, enhancing color consistency and minimizing distortion, thanks to its advanced IPS technology.
- This technology ensures superior color reproduction and brightness, making it ideal for applications where image quality is critical.
- Whether for handheld devices, industrial uses, or multimedia displays, this display guarantees an exceptional viewing experience with outstanding clarity and detail from any angle.
3.5” TFT LCD Various Application
The 3.5-inch IPS TFT LCD display is highly versatile, suitable for various applications including industrial equipment, smart home control panels, and medical devices.
In industrial settings, it excels in control panels and monitoring systems due to its durability and visibility in diverse lighting conditions.
For home automation, it provides an engaging interface for users to manage their systems effectively.
In medical applications, its clarity and color accuracy are essential for precise data representation and patient monitoring, making it a reliable choice across these critical fields.
3.5″ TFT-LCD Product Specifications
| 3.5″ TFT-LCD Product Specifications | |||
| Numero di modello | 90-03523-001 | Temperatura di esercizio | -20℃ to +70℃ |
| Dimensioni del display | 3.5″ (diagonal) | Temperatura di stoccaggio | -30℃ to +80℃ |
| Risoluzione | 320 × 480 (QVGA) | Durata del LED | 20.000 ore |
| Module Dimensions | 54.5 × 83.0 × 2.15 mm | Touchscreen | Not included |
| Area attiva | 48.96 × 73.44 mm | Rapporto di contrasto | 1000:1 |
| Luminosità | 350 cd/m² | Alimentazione | 3.3V DC |
| Interfaccia | MCU/RGB Selectable | Tipo di display | TFT-LCD a colori |
| Angolo di visualizzazione | All directions | ||
Parti personalizzabili
Cavo del display
We can adjust the length, position, and pins of the cable according to your needs, or add additional connectors to enhance its functionality. Through customization, you can make your circuit connections safer and achieve more reliable performance.
Vetro e touch screen personalizzati
Per migliorare la durata e le prestazioni del monitor, si può scegliere di avere un vetro di copertura tagliato su misura per il monitor. È possibile scegliere lo spessore più adatto e optare per il metodo di incollaggio ottico, in modo da proteggere il monitor dall'umidità e dalla rottura.
Contattaci Per ottenere la migliore soluzione personalizzata.
Beyond these tailored services, our displays excel in diverse industry applications: Medical displays feature 1000-nit brightness and antibacterial glass for clear, sterile surgical environments; automotive console displays prioritize reliability; industrial HMIs use M12 connectors and IP67 coating to withstand harsh conditions; and visual access control displays deliver high brightness, HD quality, with customizable shapes. Submit your project requirements via our form, and our experts will provide a personalized solution framework within 48 hours.
